| Mating Cycle: 5,000 Cycles | Voltage Rating: 80V DC | Operating Temperature: -40°C to 105°C |
|
Wire Processing: Panel, Crimp; Plug, Solder |
Current Rating: 50A+5A | IP Rating: IPX7(Mated) |
| Insulation Resistance: 500MΩ at DC 500V | Withstand Voltage: 1,500V AC | Salt Spray: 5% NaCI, 48h |
|
Wire Gauge: Power 9AWG/ Max Signal 20AWG/ Max |
|
Flammability Rating: UL94V-0 |
